Inverter Generator Set
KNOXGEN inverter generator sets provide clean and quiet portable power. These compact and light weight generators are the perfect match for the RV or campground, when you want all the conveniences at home or bring a digital generator to the worksite. The pure sine wave generators can run sensitive electronic equipment.
FEATURES AND BENEFITS
Quiet operation
Ultra-quiet, our portable range have specially designed acoustically insulated casings and an advanced exhaust muffler system, which drastically reduces noise. Digital throttle also reduces the noise level on our inverter generators.
Lightweight portable
Ultra-lightweight materials are used in our compact range, enabling power to be accessed in the remotest places. The alternator is directly connected to the engine, eliminating weight of the flywheel.
Certification
KNOXGEN inverter gensets have received EPA, CE, CARB, CETL and PSE certification.
Reliable
KNOXGEN inverter generators are unique in their ability to deal with surges in power demand, thanks to their Inverter technology, essential for use with sensitive electronic devices.
Low fuel consumption
On the other hand, not only makes our compact range highly cost effective, it ensures longer working times without the need for refueling.
| MODEL | IG5000i | ||
| GENERATOR SET | Rated Power | W | 3500 |
| Max Power | W | 3700 | |
| Rated Voltage | V | 230 | |
| Rated Frequency | Hz | 50/60 | |
| Rated Current | A | 15.2 | |
| THD | ≤3% | ||
| Noise Level | db@7m | 73 | |
| 75% Loading Continuous Operating Time | h | 6.5 | |
| ENGINE | Engine Model | KM170FP | |
| Engine Type | OHV, Single Cylinder, Air-cool, 4-stroke | ||
| Displacement | cc | 233 | |
| Engine Output | hp | 8.0 | |
| Engine Start | Recoil/Electric | ||
| Fuel Tank Capacity | L | 10 | |
| Oil Capacity | L | 0.6 | |
| PACKAGE | Carton Size | mm | 625*485*570 |
| Net/Gross Weight | kg | 43/45 | |
| Container load | 168/340 | ||
