MTU
MTU series gensets are available from 550kVA to 3250kVA and powered by world-famous MTUengine which is featured with reliability,advanced technology,high-class performance,environmental consciousness and long service life.
The fuel economy and environmental performance in the current outshine others in the world,nooverhauperiod up to 30000 hours,far more than the other diesel engines 10000 to 20000 hours.MDEC system also provide a fault diagnosis and fault code display function.
| Genset Model | Standb Power | Prime Power | DIESEL ENGINE | Specifications | |||
|---|---|---|---|---|---|---|---|
| kVA | kW | kVA | kW | Brand | Model | ||
| KDE-550M | 550 | 440 | 500 | 400 | MTU | 10V1600G20F | |
| KDE-660M | 660 | 528 | 600 | 480 | MTU | 12V1600G10F | |
| KDE-715M | 715 | 572 | 650 | 520 | MTU | 12V1600G20F | |
| KDE-825M | 825 | 660 | 750 | 600 | MTU | 12V2000G65 | |
| KDE-880M | 880 | 704 | 800 | 640 | MTU | 12V2000G65 | |
| KDE-1000M | 1000 | 800 | 910 | 728 | MTU | 16V2000G25 | |
| KDE-1100M | 1100 | 880 | 1000 | 800 | MTU | 16V2000G65 | |
| KDE-1250M | 1250 | 1000 | 1135 | 908 | MTU | 18V2000G65 | |
| KDE-1375M | 1375 | 1100 | 1250 | 1000 | MTU | 18V2000G26F/G76F | |
| KDE-1400M | NA | NA | 1400 | 1120 | MTU | 12V4000G14RF | |
| KDE-1660M | 1660 | 1328 | 1550 | 1240 | MTU | 12V4000G14F | |
| KDE-1800M | 1800 | 1440 | 1640 | 1312 | MTU | 12V4000G14F | |
| KDE-2000M | 2000 | 1600 | 1813 | 1450 | MTU | 12V4000G24F | |
| KDE-2250M | 2250 | 1800 | 2050 | 1640 | MTU | 16V4000G14F | |
| KDE-2500M | 2500 | 2000 | 2250 | 1800 | MTU | 16V4000G24F) | |
| KDE-2750M | 2750 | 2200 | 2500 | 2000 | MTU | 20V4000G14F | |
| KDE-3000M | 3000 | 2400 | 2750 | 2200 | MTU | 20V4000G24F | |
| KDE-3250M | 3250 | 2600 | 3000 | 2400 | MTU | 20V4000G34F | |
| Genset Model | Standb Power | Prime Power | DIESEL ENGINE | Specifications | |||
|---|---|---|---|---|---|---|---|
| kVA | kW | kVA | kW | Brand | Model | ||
| KDE-688M-60 | 688 | 550 | 625 | 550 | MTU | 12V1600G10S | |
| KDE-756M-60 | 757 | 606 | 687 | 550 | MTU | 12V1600G20S | |
| KDE-896M-60 | 896 | 717 | 815 | 652 | MTU | 12V2000G45 | |
| KDE-1000M-60 | 1000 | 800 | 910 | 728 | MTU | 12V2000G85 | |
| KDE-1137M-60 | 1137 | 910 | 1025 | 820 | MTU | 12V2000G45 | |
| KDE-1265M-60 | 1265 | 1012 | 1150 | 920 | MTU | 16V2000G85 | |
| KDE-1450M-60 | 1450 | 1160 | 1338 | 1070 | MTU | 18V2000G85 | |
| KDE-1500M-60 | 1500 | 1200 | 1362 | 1090 | MTU | 18V2000G85 | |
| KDE-1562M-60 | 1562 | 1250 | NA | NA | MTU | 18V2000G76S | |
| KDE-1875M-60 | 1875 | 1500 | 1700 | 1360 | MTU | 12V4000G14S | |
| KDE-2200M-60 | 2200 | 1760 | 2000 | 1600 | MTU | 12V4000G24S | |
| KDE-2500M-60 | 2500 | 2000 | 2275 | 1820 | MTU | 16V4000G14S | |
| KDE-2750M-60 | 2750 | 2200 | 2500 | 2000 | MTU | 16V4000G24S | |
| KDE-3125M-60 | 3125 | 2500 | 2813 | 2250 | MTU | 20V4000G14S | |
| KDE-3438M-60 | 3438 | 2750 | 3125 | 2500 | MTU | 20V4000G24S | |
| KDE-3750M-60 | 3750 | 3000 | 3450 | 2760 | MTU | 20V4000G44S | |
