KD170F

Short Description:


● Steady and reliable performance.
● Advanced noise reduction design
● Perfect injection technology
● Unique transmission system
● Quick&easy starting

FEATURES & BENEFITS

SPECIFICATIONS

PRODUCT TAGS

More simple, reliable and technological

Based on years of production and sales experience, the core concept of KNOXGEN is to solve power problems for clients with advanced technology. In the perspective of users, the products of KNOXGEN are characterized by low fuel consumption and low maintenance cost. KNOXGEN engines comply with the latest emissions regulations through our original advanced diesel engine technologies.

Features & benefits

Advanced noise reduction design

The efficient muffler reduces the exhaust noise significantly. Large air filters minimize intake noise. The engine noise is further reduced by the high strength cylinder block, cylinder head cover and the reasonable timing structure of intake and exhaust valves.

Perfect injection technology

KNOXGEN independently developed precise injection system, ensure efficient fuel injection. High precision injection pump and direct injection system make fuel consumption reach the ideal level. Good air intake and sufficient combustion make its emission lower to meet EPA standard.

Unique transmission system

The new generation of KNOXGEN portable diesel engine adopts well-designed gear transmission mechanism, which can greatly reduce vibration and noise.





  • Previous: KD178F
  • Next: no more

  • Diesel Engine
    KD170F
    Type
    Single-cylinder, vertical, air-cooled, four-stroke, direct injection
    Bore× Stroke mm70×55
    DisplacementL0.211
    Compression ratio
    20
    Rated power/Rated speedkW/r/min2.5/3000   2.8/3600
    The lowest speed at zero loadr/min_x005f≤1300
    Lubricating system
    Pressure splashed
    Starting system
    Recoil starter or Electric starter
    Rotation direction (face to the output axle)
    Anticlockwise
    Fuel tank capacityL2.5
    Fuel consumption(g/kW.h)/r/min280.23000 288.3/3600
    Lube oil type
    CD grade or SAE 10W-30, 15W-40
    Lube oil capacityL0.75
    Starting Motor CapacityV, Kw12V 0.8kW
    Charging Generator CapacityV, A12V 3A
    Accumulator CapacityV, Ah12V 24Ah-36Ah
    Overall dimension(L×W×H)mm335×380×415
    Dry weightkg≤27
